Jucolor 120cm Packaging Printing Machine for Paper Bag Pizza Box Corrugated Box Tissue Printing
Basic Information
Jucolor CJ-SP1200 Industry carton Package printer is the ideal option for fast speed and high-volume packaging printing solution, equipped with auto-feeder allows less labor intervention, time-saving and cost-saving. Water based inks, no odor, no pollution, environmentally friendly, no impact on human health. Optimal for printing Corrugated boxes, cartons, handbags.packaging boxes, brochures, booklets, labels
|
Printer name
|
CJ-SP1200 Carton one pass printer
|
||||||
|
Printhead
|
1~2pcs * HP widepage industrial printheads
|
||||||
|
Maximum printing thickness
|
2’’(50mm)
|
||||||
|
Flatbed Type
|
Vacuum adsorption, auto continual conveyor
|
||||||
|
Control syetem
|
Upgraded Giftec single pass software, integrated computer with software pre- installed
|
||||||
|
Media Release device
|
Integrated friction feeder *Optional
|
||||||
|
Media Take up device
|
Adjustable take up tray *Optional
|
||||||
|
X axis adjustment
|
Dual leadscrews, automatic & manual adjustment
|
||||||
|
Aqueous/ dye/ pigment water-based ink
|
Temperature
|
15℃ ~ 30℃(59ºF～86ºF), Humidity30%-70%
|
|
|
Color Configuration of printing
|
Cyan(C), Magenta(M), Yellow(Y), Black(K)
|
Voltage
|
220V/AC(±10%), 50Hz, 1KW(Max.)
|
|
Ink tank
|
500ML/color
|
Acoustic noise level
|
70db(A) or less
|
|
Ink supply
|
Continual ink supply system (CISS); Intelligent constant sub-ink tank pressure
|
Operating system
|
Windows® 7/10 (64 bit) Recommend
|
|
Operating system
|
Windows® 7/10 (64 bit) Recommend
|
CPU
|
Intel® Core™ i5, 2.5 GHz or more
|
|
HDD
|
Install space 1 GB or more; Working space 100 GB
|
HDD
|
Install space 1 GB or more; Working space 100 GB
|
|
Storage
|
RAM>8G
|
Data Interface
|
Gigabit Ethernet port
|
|
Print head
|
A4 head * 1pcs
|
A4 head * 2pcs
|
A4 head * 3pcs
|
A3 head * 1pcs
|
A3 head * 2pcs
|
A3 head * 3pcs
|
|
|
Printing width
|
8.46’’
|
16.93’’
|
25.39’’
|
11.81’’
|
23.62’’
|
35.43’’
|
|
|
Material width
|
23.62’’
|
31.5’’
|
31.5/47.2’’
|
23.62’’
|
31.5’’
|
47.24’’
|
|
|
Printer size
(L*W*H) |
59*33.5*51.6’’
|
59*40.6*51.6’’
|
65*60.2*70.1’’
|
59*33.5*51.6’’
|
59*40.6*51.6’’
|
65*60.2*70.1’’
|
|
|
Package size
(L*W*H) |
75.6*64.2*53’’
|
75.6*64.2*53.1’’
|
77.2*65*67.3’’
|
75.6*64.2*53.1’’
|
75.6*64.2*53.1’’
|
77.2*65*67.3’’
|
|
|
Net Weight
|
300KG
|
350KG
|
450KG
|
300KG
|
350KG
|
450KG
|
|
|
Gross weight
|
400KG
|
450KG
|
550KG
|
400KG
|
450KG
|
55
|
|
| Printer name | Jucolor Package Printer | Ink type | Water-based pigment ink, Dye ink |
| Model | CJ-BP500 | Ink Color | CMYK |
| Print head | HP A3/A4 Industry head | Resolution | 1200*300/1200*600/1200*1200dpi |
| Print wide | 20/30cm | Medias wide | Less than 50cm |
| Media Release device | Integrated friction feeder | Print height | 5cm（Support customization） |
| Print speed | 20-40m/min | Consumable cost | $0.43/square meter |
| Workable medias | carton corrugated box, pizza box, non-woven fabric, sack handbag, canvas bag, cotton bag, wood board, paper cardboard, disposable paper cup, egg box, etc... | ||
| Flatbed Type | Vacuum adsorption, auto continual conveyor | Ink supply | Continual ink supply system (CISS)500ML/color |
| Temperature | 15℃~ 30℃(59ºF～86ºF), Humidity30%-70% | Voltage | 220V/AC(±10%), 50Hz, 1KW(Max.) |
| Printer size | 175*86*66cm, 165kg | Packing size | 195*100*80cm, 225KG |
